Klik KLDS8 Marshalling Box 8 Way Lighting Distribution Outlet System

Klik KLDS8 a 4 pin marshalling box part of the Hager Klik lighting distribution connector system. Plug-in convenience and versatility for lighting. It is a unique modular plug and socket interface provides simultaneous mechanical and electrical connection in one click-in action. Used in conjunction with 3 and 4 pin klik plugs luminaires can be connected in seconds, in absolute safety, without circuit isolation. All live contacts are inaccessible and the earthing connection is made before any other. Klik plugs and sockets feature solid brass terminals and phosphor bronze contacts for good conductivity.

• Number of lighting outlets: 8
• Socket outlets accept either Klik lighting 3 pin or 4 pin plugs or Klik pre-wired leads
• Main terminal rating: 16A
• Socket outlet rating: 6A
• Separate terminals for flexible conductors, rating 10A
• Dual switch capability: Yes
• Klik marshalling boxes can be separated into two independently switched circuits
• Circuits can be controlled via wall switch or occupancy sensor
• Short circuit tested 1500A conditional rating
• Constructed from robust aluminium extruded body
• Mounting: Suspended by steel fasteners on rod, fixed direct to lighting trunking or directly to ceiling or wall with No.8 screws
• Cable entries will accept 20mm, can be drilled out to 25mm.
• Self-retained cover screws
• All plastic 'V0' rated
• Main terminal capacity: 5 x 4mm2
• Flexible conductor terminal capacity: 1 x 1mm2
• Voltage: 230V
• Height: 222mm
• Width: 388mm
• Depth: 73mm
• Inflammability: UL 94 V0
• Standards: BS 5733:2010
