Hager RCBO Type C Single Pole 32A 30mA
£59.70
£49.75
In stock
Code
ADC432U
Hager Type C 32A Single Pole RCBO
Key Features of Hager RCBO Type C Single Pole 32A 30mA:
- Poles: Single Pole
- Trip Current: 30mA
- Trip Curve: Type C
- Number of Modules: 1
- Fixing Mode: DIN Rail Type O
- Rating Current: 32A
- Rated Operational Voltage: 230/240V
- Frequency: 50/60Hz
- Type of Supply Voltage: AC
- Rated Impulse Withstand Voltage: 4000V
- Breaking Capacity: Dual Rated 10kA (IEC 60898)
- IP rating: IP20
- Height: 115mm
- Width: 17.8mm
- Depth: 70mm
- Standards: BS 61009-1, BS 61009-1
| Model Number | ADC432U |
|---|---|
| Brand | Hager |
| Rating | 32A |
| Rated Tripping Current | 30mA |
| Trip Curve | Type C |
| Breaking Capacity | 10kA |
| Modules | 1 |
| Terminal Capacity | 16mm2 flexible conductor, 25mm2 rigid conductor |
| Voltage | 230V |
| IP Rating | IP20 |
| Height | 115mm |
| Width | 17.5mm |
| Depth | 70mm |
| Manufacturer Guarantee | 1 Year |
| Standards | BS 61009-1, EN 61009-1 |
